Key Features

• Superb low speed performance.
• Switchable 3-mode gyro stabilisation system.
• Perfect for basic training.
• Fully aerobatic.
• Takes a standard 3S 2200 – 3200mAh LiPo.
• Durable wire undercarriage with solid mountings.
• Aerodynamically efficient swept winglets.
• Flap-equipped.
• Made from lightweight, durable EPO foam.
• Screw together assembly (no glue needed).
• Spacious battery compartment.
• Supplied with pre-fitted motor, ESC and servos.
• Features LED wingtip navigation lights.
• Numerous moulded scale fittings.
• Float set available as an optional extra.

What’s in the Box

• 1x Factory assembled and decorated fuselage and fin.
• 1x Factory assembled and decorated 2-piece wing.
• 1x Factory assembled and decorated tailplane.
• 1x Pre-installed 3536 850KV motor.
• 1x Pre-installed 30A ESC with XT60 connector.
• 6x Pre-installed high quality 9g metal gear servos.
• 1x Pre-installed high quality 13g metal gear servo (nose wheel).
• 1x Undercarriage set with wheel spats.
• 1x 2-blade 11 x 7″ propeller and spinner.
• 1x Wing spar.
• 1x Screw and pushrod set.
• 1x Wing strut set.
• 1x Scale aerial set.
• 1x Comprehensive instruction manual.

Needed to Complete

• 1x 6-channel transmitter and receiver combo.
• 1x 3S 2200 to 3200mAh LiPo with XT60 connector.
• 1x 3S compatible LiPo balance charger.

Weights & Dimensions

Shipping Weight	0.00kg	0.00lbs
Product Length	1,110mm	43.7in
Product Wingspan	1,450mm	57.1in
Product Wing Area	30dm2	464in2

• Connector: XT60
• Completion Level: PNP
• Experience Level: Beginner / Intermediate
• Assembly Time: 30min
• Recommended Usage Environment: Outdoors / large field
• Material: EPO

• Motor/Engine: 3536 850KV brushless outrunner
• Servos: 7x Digital 9g
• ESC: 30A with XT60 connector

Spec

• Brand: Arrows Hobby
• Part No: ARR016P
• Barcode: 5051121254129
• Power: Electric
• Assembly Level: PNP (Plug n Play) / RR
• Flying Style: Sport
